UL和REACH认证 120灯SMD2835外贸出口照明软灯带

LED照明和装饰灯带, SMD2835 SMD3528

产品型号: ADY-UL-2835-120-1024P2
产品名称: 外贸出口UL和REACH认证120灯SMD2835照明软灯带
电气参数: DC24V, 12.8w/m
基板规格: 10mm宽FPCB, 白色, 也可定制其它颜色
光源规格: SMD 2835 单白光灯珠, 120灯/米, RA80/90/95
防水等级: IP20 (可定制IP20/IP67, 滴胶防水，套管防水，灌胶防水，霓虹管，铝槽线形灯等)
发光角度: 120°
发光颜色: 白光, 2200K-8500K, RA80/90/95
包装尺寸: 5M/ 卷, 静电袋包装, 5000 x 10 x 1.8 (mm)
配套服务: 可提供配套控制器及电源, 效果图, 现场效果调试等

UL Listed High Efficiency RA80/RA90/RA95 SMD2835 Flex led strips

Overview:

UL Listed 120led/m RA80 SMD2835 Flex led strips, 120led/m, 12V/24V, 4-14.4w/m, 8/10mm white PCB, CRI>90, 2800K-6500K, 2-Pin ordinary or waterproof connect wire output; high color efficiency, uniform illumination, can be bent freely, not easy to be break and not effect the current,.

Data sheet:

Product:	UL Listed 120led/m RA80 SMD2835 Flex led strips
Item No.:	ADY-UL-2835-120-1024P2
LED:	SMD2835, 120LEDs/m, RA80/90, 2700K, 3000K, 4000K, 6000K
View angle:	120°
IC Chip:	N/A
Input voltage:	24V
Power:	12.8w/m
Size:	5000x10x1.8(mm)

Features

1) 99.99% golden wire and copper support, super bright leds, stable and reliable.
2) High lumen output, popular with very high cost-effective.
3) Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
4) UL/CE/ROHS certification.
5) Warranty: 3 years.

Typical SMD2835 LED strips:

ADY-UL-2835-182-1024P2 — SMD2835, 182led/m, DC24V, 15w/m, 10mm FPCB, 1800lm/m

P/N: ADY-UL-2835-240-1024P2 — SMD2835, 240led/m, DC24V, 20w/m, 10mm FPCB, 2100lm/m, RA80/90, 1800K-7500K

Why choose us:

Firstly, Inspected 100% of all products 6 times, professional equipments.

Strict at color management — Secondly, Strict color management

Thirdly, Customizable connect wires and multiple choices of adhesive tapes and waterproof

Fifthly, Customizable CCT, CRI, and power

Lastly, the third-party certifications, UL, CE, ROHS, UKCA, TUV-CE, and REACH

Application:

1) Architectural decoration Lighting; Backing lighting for signage letters;
2) Decoration lighting for under water project; Archway /Canopy & Bridge Edge Lighting;
3) Auditorium walkway lighting, Amusement park / Theater lighting;
4) Stairway Accent Lighitng, Channel letters lighting;
5) Furniture Decoration Lighting; Cove Lighting etc;

Order info:

SN	P/N	LED	PCB Width	Voltage	Power	Waterproof
1	ADY-UL-2835-060-08xxP2	60led/m	8mm	12V/24V	5.8w/m	IP20/IP65/IP67
2	ADY-UL-2835-120-10xxP2	120led/m	10mm	12V/24V	12.8w/m	IP20/IP65/IP67
3	ADY-UL-2835-180-1024P2	180led/m	10mm	24V	15w/m	IP20/IP65/IP67
4	ADY-UL-2835-196-1024P2	196led/m	15mm	24V	20w/m	IP20/IP65/IP67
