3oz厚实质感FPCB软板120灯2835照明软灯条
- 产品型号: ADY-2835-120-0824A3
- 产品名称: 3oz厚实质感FPCB软板120灯2835照明软灯条
- 电气参数: DC 24V, 6w/m (功率可定制，功率越大，亮度越高，发热越大)
- 基板规格: 8mm宽FPCB, 白色, 也可定制其它颜色
- 光源规格: SMD 2835 单白光灯珠, 120灯/米, RA80
- 防水等级: IP20 (可定制IP20/IP67, 滴胶防水，套管防水，灌胶防水，霓虹管，铝槽线形灯等)
- 发光角度: 120°
- 发光颜色: Warm white, Natual white, Cold white, 2800-6500K
- 包装尺寸: 5M/ 卷, 静电袋包装, 5000 x 8 x 1.2 (mm)
- 配套服务: 可提供配套控制器及电源, 效果图, 现场效果调试等
规格参数：(功率，颜色，防水级别，都可以接受定制)
| SPN | LED | LED/m | CRI | Color | Voltage | w/m | PCB | Cut Length | Waterproof |
| ADY-2835-120-0524DC | SMD2835 | 120 | 80/90 | WW | NW | CW | DC 24V | 6 | 5mm | 8.33mm | IP20 |
| ADY-2835-120-0812DC | SMD2835 | 120 | 80/90 | WW | NW | CW | DC 12V | 6 | 8mm | 8.33mm | IP20 |
| ADY-2835-120-0824DC | SMD2835 | 120 | 80/90 | WW | NW | CW | DC 24V | 6 | 8mm | 8.33mm | IP20 |
| ADY-2835-120-0812XX | SMD2835 | 120 | — | 12种颜色可选 | DC 12V | 6 | 8mm | 25mm | IP20 |
| ADY-2835-120-0824XX | SMD2835 | 120 | — | 12种颜色可选 | DC 24V | 6 | 8mm | 50mm | IP20 |
| ADY-2835-120-0824M20 | SMD2835 | 120 | 80/90 | WW | NW | CW | DC 24V | 6 | 8mm | 41.7mm | IP20 |
| ADY-2835-120-0824P7 | SMD2835 | 120 | 80/90 | WW | NW | CW | DC 24V | 6 | 8mm | 50mm | IP67 |
| ADY-2835-120-0824P8 | SMD2835 | 120 | 80/90 | WW | NW | CW | DC 24V | 6 | 8mm | 50mm | IP68 |
| ADY-2835-120-0824A3 | SMD2835 | 120 | 80/90 | WW | NW | CW | DC 24V | 12 | 8mm, 3oz | 50mm | IP20 |
| ADY-2835-180-1024A3 | SMD2835 | 180 | 80/90 | WW | NW | CW | DC 24V | 14.4 | 10mm, 3oz | 33.3mm | IP20 |
